Ultrasonic Plastic Welding Machine DX6
Model · DX6
Servo-controlled plastic welding with independent pressure, speed and amplitude adjustment, recipe storage and weld-data connectivity.
- Frequency options
- 15 / 20 / 35 kHz
- Power
- 3200 W at 15/20 kHz; 1500 W at 35 kHz
- Working stroke
- 100 mm
Designed for your process.
Servo-controlled plastic welding with independent pressure, speed and amplitude adjustment, recipe storage and weld-data connectivity.
The right result depends on the complete setup: equipment, tooling, material and process settings. Use the technical information below to begin selection, then confirm the configuration around your production requirements.
Read the selection guide →From equipment to application.
Explore relevant workpieces and industry contexts.
⊕Automotive manufacturing
Illustrative automotive production context for assembly and integration discussions.
⊕Plastic enclosures & electronics
Conceptual polymer parts and fixtures for joint-design discussions.
⊕Medical-device components
Conceptual translucent polymer components in a clean assembly environment.
AI-generated application concepts illustrate industry contexts, not actual customer facilities or verified production results. Equipment selection is confirmed for each project.
The details that matter.
| Frequency options | 15 / 20 / 35 kHz |
|---|---|
| Power | 3200 W at 15/20 kHz; 1500 W at 35 kHz |
| Working stroke | 100 mm |
| Motion system | Servo motor |
| Touchscreen | 10 inch |
| Parameter recipes | 10 sets |
| Welding modes | Time / energy / ground / absolute depth / relative depth |
Values describe the listed product or available configurations; they are not necessarily combined in one build. Confirm the model, tooling and application before ordering.
Product information reviewed: 2026-10-09
Useful answers.
What is the DX6 used for?+
Servo-controlled plastic welding with independent pressure, speed and amplitude adjustment, recipe storage and weld-data connectivity.
What should I provide for model selection?+
Share your material, part drawing, joint or cutting geometry, target output and installation constraints. For replacement components, include the existing generator, frequency and connection dimensions.
Can I confirm a configuration before ordering?+
Yes. Use the inquiry form to describe your application and the required model. Final tooling, electrical supply, interfaces and performance targets should be agreed for your project.
